The CST Pump Package Design Features

1. Heavy duty construction horizontal centrifugal solid handling pump type designed for multipurpose mining and related dewatering applications.
2. Vacuum-assisted self-priming with a simplex separator where separate air from the liquid.  Through a vacuum pump provided in the system, the air is sucked and makes automatic rapid priming.
3. P-I-P (Prime-Idle-Prime) Auto-Switch System automatically operates from priming to “idle” position after priming process is completed and back to priming as process demanded.
4. Dry Running Protection System provide three(3) types of dry running seal options; (1) oil reservoir lubricated mechanical seal, (2) air cushion protected mechanical seal, and (3) grease lubricated lip seals configuration. Either of them can secure the pump dry running condition for a long period operation.
5. Equipped with diesel power unit either Cummins or other heavy duty diesel engines.
6. Heavy duty fabricated steel construction baseplate.

Performance Envelope-
Design Standard – ANSI/ASME B73.1.
Design Pressure Rating – Up to 15 barg.
Temperature Rating – Up to 90 °C.
Flowrate – Up to 1200 m³/h.
Differential Head – Up to 100 m.
Speed – Up to 3600 rpm.
